Description
Honda DST Mini VCI Diagnostic System
Introducing the Denso DST DST-010, the cutting-edge diagnostic interface designed specifically for Honda, Subaru, Toyota and Daihatsu vehicles. This innovative tool is the successor to the trusted Denso DST-i interface, boasting enhanced capabilities and improved performance to meet the demands of modern automotive diagnostics.
Equipped with a powerful 32-bit microcomputer, the DST-010 supports a wide range of protocols including ISO9141(K/L), HS-CAN, and specialized Honda and Subaru protocols. This ensures comprehensive diagnostic coverage for various systems and modules within the vehicle.
One of the standout features of the DST-010 is its built-in wireless module, enabling seamless Wi-Fi and Bluetooth connectivity to a PC. This allows for convenient data transfer and real-time monitoring, enhancing efficiency and productivity in diagnostic procedures.
- CPU, 32-bit microcomputer
- USB2.0 x 1 (Mini-DIN connector)
- Wireless LAN IEEE802.11bgn 2.4GHz
- Bluetooth IEEE802.15.1 Ver.4.0/Class1
- Vehicle communication, ISO9141(K/L), HS-CAN
- Vehicle power supply DC6.5 ～ 32V
- USB power (BUS power) DC4.75 ～ 5.25V
- Power consumption MAX. 2.5W (12VDC)
- Main unit dimensions 47.2mm (W) x 73.0mm (H) x 22.5mm (D)
- Weight 60g
What In The Box:
- Denso DST-010 Nano VCI (Yellow)
- USB Cable [1 Meter]
- USB Bracket
- Instruction Manual
